RD90N-1 2400RPM 9HP Heavy Equipment Engines For Water Pump
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| POWER: | 9HP | COLOR: | BLUE |
|---|---|---|---|
| DIMENSION: | 595*335*490MM | 20%22CONTAINER CAN LOAD: | 108SETS |
| High Light: | RD90N-1 Diesel Engine,2400RPM Heavy Equipment Engines,9HP Heavy Equipment Engines |
||
Heavy Equipment Engines , Constructure Machinery Engine , Engine For Water Pump
RD90N-1 DIESEL ENGINE,CONDENSER WITHOUT HEAD LAMP,THE MAXIMUM OUTPUT IS 6.62KW(9HP).MAINLY USED IN CONSTRUCTION MACHINERY.
| MODEL | RD90N-1 |
| TYPE | SINGLE CYLINDER,HORIZONTAL,4-STROKE,WATER COOLING |
| DISPLACEMENT (L) | 0.487 |
| BORE X STROKE (MM) | 86X84 |
| SPEED (RPM) | 2400 |
| CONTINUOUS OUTPUT (KW/HP) | 5.88/8 |
| MAXIMUM OUTPUT (KW/HP) | 6.62/9 |
| COMBUSTION SYSTEM | DIRECT INJECTION |
| SPECIFIC FUEL CONSUMPTION (G/KW.H) | 258 |
| STARTING METHOD | KEY STARTER |
| LUBRICATING OIL CAPACITY (L) | 2.3 |
| WATER TANK CAPACITY (L) | 2.1 |
| NET WEIGHT (KGS) | 88 |
| GROSS WEIGHT (KGS) | 93 |
| OVERALL DIMENSIONS (LXWXH:MM) | 595X335X490 |
| SET/20" CONTAINER | 108 |
